Product Specifications
| Parameter | Specification |
|---|---|
| Connector Type | LC/UPC to FC/UPC (Hybrid) |
| Gender | Female-to-Female |
| Fiber Mode | Singlemode OS2 9/125μm |
| Channel Configuration | Simplex (Single-Fiber) |
| Alignment Sleeve | Precision Zirconia Ceramic |
| Insertion Loss | ≤0.3 dB (Typical) |
| Return Loss | ≥50 dB (UPC Polish) |
| Durability | ≥500 Mating Cycles |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Housing Material | High-Strength Plastic or Metal (Optional) |
| Mounting Type | Panel-Mount with Clips |
| Compliance | IEC 61754, TIA-568, RoHS |
Flexible Customization & OEM/ODM Services
DIMI offers extensive customization capabilities to meet precise project requirements and OEM integration needs:
Connector Combinations
Full range of hybrid and matched-pair configurations including LC–LC, SC–SC, FC–FC, ST–ST, LC–SC, LC–FC, LC–ST, SC–FC, SC–ST, FC–ST, and other cross-platform adapter types.
Polish Types & Fiber Modes
Available in UPC and APC polish variants for singlemode applications (OS2 9/125μm) and multimode versions (OM3 50/125μm, OM4 50/125μm) to match network transmission requirements.
Channel Configurations
Simplex (single-fiber), duplex (dual-fiber), quad (four-fiber), and multi-core adapter modules designed for various patching density and bandwidth requirements.
Footprint & Mounting Options
Standard SC footprint, rectangular footprints for high-density panels, custom mounting ears and clip designs, shuttered variants, and specialized panel integration geometries.
Housing Materials & Colors
High-strength engineering plastic or metal housing options with color coding matched to fiber type standards or custom color schemes for network identification systems.
Marking & Labeling
Custom logo printing, sequential port numbering, laser-etched part numbers, color-coded tabs, and customer-specific labeling to integrate with existing documentation.
Packaging Solutions
Bulk packaging for OEM panel assembly lines, individual anti-static bags with barcode labels, pre-sorted adapter kits, and custom packaging matched to customer workflows.
OEM/ODM Collaboration
DIMI's OEM/ODM services enable panel manufacturers and system integrators to specify exact adapter configurations that align with their product designs and project requirements.
Application Scenarios
Data Center Fiber Patching
Deployed in structured cabling patch panels and MDA/HDA distribution frames to interconnect server switches, storage arrays, and backbone uplinks.
Telecommunications Central Office
Installed in main distribution frames (MDF) and optical distribution frames (ODF) within carrier central offices to provide flexible interconnection.
FTTx/FTTH Distribution
Utilized in fiber access network distribution points including street cabinets, building entry terminals, and floor distribution boxes.
Enterprise Campus Networks
Deployed in telecommunications rooms and intermediate distribution frames (IDF) throughout multi-building campus environments.
Test and Measurement
Incorporated into fiber optic test equipment racks and instrument panels to provide interface flexibility for validation testing.
OEM Panel Manufacturing
Integrated by panel manufacturers, enclosure builders, and turnkey solution providers into pre-terminated fiber distribution products.
Series Lineup & Compatibility
The DIMI fiber optic adapter series encompasses a comprehensive range of connector configurations to address diverse network connectivity requirements:
Standard Matched-Pair Adapters
LC-to-LC, SC-to-SC, FC-to-FC, and ST-to-ST adapters in simplex, duplex, and quad configurations for homogeneous connector environments. Available in both singlemode (OS2) and multimode (OM3, OM4) variants with appropriate color coding.
Hybrid Cross-Platform Adapters
LC-to-SC, LC-to-FC, LC-to-ST, SC-to-FC, SC-to-ST, and FC-to-ST combinations enabling interconnection between different connector standards within mixed-technology networks and equipment migration scenarios.
Shuttered Safety Adapters
Spring-loaded shutter mechanisms protect exposed ferrule interfaces in live fiber panels, preventing accidental eye exposure to active laser sources and reducing dust contamination in unused ports. Available for LC, SC, and FC connector types.
Multimode Options
OM3 and OM4-rated adapters with aqua housing color coding for 10G/40G/100G short-reach applications in data centers, storage area networks, and high-performance computing clusters.
Why Choose DIMI Fiber Optic Adapters?
Uncompromising Quality
DIMI hybrid fiber optic adapters deliver the technical performance, manufacturing consistency, and supply reliability demanded by professional network deployments.
Comprehensive Testing
Our factory quality control processes ensure every adapter meets published specifications through comprehensive optical and mechanical testing before shipment.
