What are Suspension Clamps
Suspension clamps are devices used to support and secure overhead cables/conductors, connecting them to insulators or tower arms. They allow the conductor to hang freely while providing mechanical support, preventing conductor damage caused by excessive stress.
In fiber optic networks, they are primarily used for installing ADSS and OPGW cables, serving to support cable weight, reduce static stress, protect fiber transmission performance, and provide mechanical protection. It's worth noting that suspension clamps are not used independently, but work together with various fittings to form a complete support, fixing, and protection system. For example, suspension clamps do not bear full tension and need to be used complementarily with tension clamps. The two often appear alternately in the same line section, with a typical configuration being preformed suspension clamp matched with helical tension clamps.
Why Do We Need Suspension Clamps?
Overhead optical cables (ADSS/OPGW) are exposed to complex outdoor environments for extended periods, facing high exposure to environmental changes, material sensitivity where any local damage can lead to signal problems, and the need to withstand both static weight and sudden dynamic loads. With a service life of 20-30 years, cumulative damage must be prevented. Without suspension clamps, stress concentration damage, excessive sagging, transmission performance degradation, and shortened overall service life can occur at any time.
Classification by Cable Type
ADSS Suspension Clamps
ADSS Suspension Clamp Characteristics
ADSS suspension clamp is resistant to high-voltage electric field corrosion and UV aging. ADSS cables derive their tensile strength primarily from aramid yarn (RTS typically 4-50kN), with weather-resistant outer sheaths. Suitable for parallel installation on high-voltage transmission line (110kV-500kV), spanning 100-600m, providing linear support while effectively avoiding electrical corrosion and lightning strike risks.
Clamp Design Features
ADSS cable suspension clamps use aluminum suspension clamp housing with rubber lining (EPDM or neoprene rubber), combined with helical suspension clamp structure, providing uniform grip force (10%-20% RTS) and allowing axial micro-movement to accommodate temperature changes. They offer strong vibration resistance, can serve as temporary pulleys for angle ≤30°, are suitable for spans within 600ft, require no tools for easy installation, and are fixed to poles and towers via U-bolts or hooks.
Application Type Classification
Short-span applications (<100m): Straight suspension clamp, used for low-voltage line retrofits and tangent towers.
Medium-span applications (100-600m): Double suspension clamp layer helical type, suitable for high-voltage parallel installation, requiring combination with vibration dampers.
High-load applications: Reinforced type required, resistant to ice and wind loads, used in mountainous and harsh environments.
ADSS Suspension Clamp
The DIMI ADSS Suspension Clamp is designed for the elastic, secure support of ADSS (All-Dielectric Self-Supporting) fiber optic cables on straight-line poles or towers. By distributing mechanical loads and minimizing stress on the cable jacket and fibers, it helps extend cable lifetime and ensures stable optical performance in overhead power and communication networks.
OPGW Suspension Clamp
OPGW Cable Suspension Clamp Characteristics
OPGW suspension clamp for Optical Ground Wire contains metallic components (aluminum-clad steel), providing both communication and lightning protection functions. With robust structure and high mechanical load resistance, it's suitable for new high-voltage lines (220kV and above) in large-span, high-load environments.
High Temperature and Electrical Requirements
For high temperature requirements: Clamp materials must withstand extreme temperature variations, typically -40°C to +200-300°C. Particularly during short-circuit faults, OPGW can instantaneously heat to 200-300°C (depending on short-circuit current and duration). Elastomer inserts like EPDM rubber can resist ozone, weathering, and temperature extremes, preventing permanent deformation from compression. Testing includes temperature rise under short-circuit current to ensure the clamp doesn't melt or fracture. For HTLS cables, clamps must match high-temperature requirements.
For electrical requirements: Equipped with current transmission tabs that directly bond OPGW to ground wire, eliminating current transmission through clamp components. Standard tabs are suitable for left-lay OPGW, with optional ground wire assemblies (copper or aluminum, 4' long) rated for high fault currents (dual ground wires can increase capacity). Electrical continuity is provided through integral bonding points connecting to support structures or ground points, ensuring low resistance paths (DC resistance must not exceed manufacturer-specified values). Die-cast aluminum bases ensure OPGW electrical bonding. Testing includes short-circuit testing (IEEE 1138) to verify component integrity. Performance standards must comply with IEEE 1138 (including installation testing and resistance measurement) and ANSI C29.7-1986. Clamp slip load is initially 10-20% of OPGW rated strength, with tension testing to 25% RTS. AFL OPGW suspension clamp is one example that meets these standards.
Application Type Classification
High-voltage ground wire replacement: Used for combined lightning protection and communication, suitable for lightning-prone areas.
Large-span applications: Supports long spans with strong ice load resistance.
Short-circuit withstand applications: Withstands electromagnetic forces, suitable for high fault current lines.
Differences from ADSS Clamps
OPGW clamps use reinforced helical rods with grounding clamps and high-temperature metal materials, providing stronger grip force and robust structure. ADSS clamps are all-dielectric with no grounding, emphasizing flexibility and bend protection. OPGW is suitable for ground wire positions, while ADSS is suitable for phase conductor positions. Installation is similar for both, but OPGW requires consideration of short-circuit current.
Figure-8/Butterfly Cable Suspension Clamps
Self-Supporting Cable Characteristics
Figure-8 or butterfly cables are self-supporting, containing a cable portion plus steel wire/FRP messenger (3-11mm), suitable for short spans (<90m). They offer low cost, easy installation, and are ideal for FTTH last-mile access.
Gripping Messenger and Cable
3 bolt suspension clamp or double-sided design primarily grips the messenger, with the cable hanging without direct force. UV-resistant plastic with galvanized steel provides slip resistance, vibration resistance, and easy installation while avoiding overload damage.
Standard Optical Cable Suspension Clamps
Duct Cable Aerial Installation
When bringing standard duct/direct-buried cables (non-self-supporting) aerial, J hook suspension clamp or tang suspension clamps are used, secured to poles and towers with stainless steel straps, ensuring proper bend radius and stress distribution.
Temporary/Permanent Applications
Temporary: Construction transitions, short-distance assistance, supporting quick installation.
Permanent: Fixed at access points or crossing pole routes, suitable for 5-20mm diameter round optical cables, providing mechanical support and vibration protection.
Application Type Classification
Pole and tower fixing: Used for ADSS transitions near high-voltage areas.
Wall/bracket mounting: FTTH access, combined with messenger wire.
Multi-purpose: Compatible with CATV and telephone lines, serving telecom drop suspension clamps applications.
Mechanical Performance of Suspension Clamps
Mechanical performance is the core indicator for evaluating suspension clamp quality and applicability. A qualified suspension clamp must withstand various static and dynamic loads during long-term service while ensuring cable safety and network reliability. Evaluation requires three key mechanical performance parameters:
Rated Tensile Load
The most basic and important performance indicator of suspension clamps, representing the maximum tensile force value that can be continuously withstood under standard test conditions without failure, permanent deformation, or functional loss. This value is typically expressed in kilonewtons (kN) or kilograms-force (kgf).
It should be noted that rated tensile load is not the ultimate failure load of the suspension clamp, but rather the working load upper limit after considering safety factors.
Gripping Strength
Gripping strength is the clamping capability between the suspension clamp and optical cable, determining whether the cable will slip from the clamp when subjected to longitudinal tensile force. It is a relatively complex performance parameter involving friction coefficient with the cable and anti-slip performance. Standard grip testing is a critical aspect of suspension clamp performance.
Fatigue Performance
Fatigue performance reflects the suspension clamp's ability to resist fatigue failure under long-term cyclic loading. Due to wind vibration, temperature changes, and other factors, overhead optical cables continuously endure dynamic loads. Fatigue performance directly determines the actual service life of suspension clamps.
Suspension Clamp Selection Process
Determine Cable Type and Specifications
Cable type directly determines the suspension clamp's structural form, material requirements, and performance indicators. Using the wrong type of suspension clamp may result in:
Insufficient grip force, causing cable slippage
Corona discharge (ADSS cable)
High-temperature damage (OPGW cable)
Cost waste (over-design)
Calculate Design Load
Design load is the maximum longitudinal tensile force the suspension clamp needs to withstand under the most unfavorable conditions. It is the core basis for selection. Load calculation for overhead optical cables at suspension clamps includes basic tension load, wind load increment, ice load increment, and dynamic coefficient.
Evaluate Environment
Under the same load, different environments have completely different requirements for suspension clamp materials, coatings, and structural forms. Inadequate environmental assessment can lead to:
Premature corrosion failure (coastal, industrial areas)
Accelerated material aging (high temperature, strong UV)
Decreased electrical performance (ADSS corona)
Increased maintenance costs
Select Suspension Clamp Model
Based on the results of the first three steps, make priority selections:
Load matching: Rated tensile load (RML) ≥ Design load × Safety factor
Size compatibility: Applicable cable diameter range includes actual cable - whether 1/2 suspension clamp, 3/4 suspension clamp, or other sizes
Environmental adaptation: Materials and coatings meet environmental requirements
Structural form: Select helical/bolted type based on cable type
Cost optimization: Choose the most cost-effective option meeting above conditions
Verify Compatibility
Even with matching load and dimensions, compatibility issues may still exist, such as installation methods incompatible with site conditions, mismatched accessory fittings, interference with other systems, or maintenance difficulties.
Common Suspension Clamp Failures and Causes
Clamp Loosening
Clamp loosening failures generally manifest as clamp displacement on the pole/tower, cable sliding within the clamp, bolt loosening, helical rod loosening, and abnormal noise at connections. There are four main causes of loosening:
Installation issues: Insufficient initial tightening torque, non-standard helical rod wrapping, failure to use anti-loosening devices, incorrect installation sequence, etc.
Vibration factors: Long-term wind-induced vibration, traffic-induced mechanical vibration, aeolian vibration and galloping, sub-span oscillation, etc.
Thermal expansion and contraction: Material expansion coefficient mismatch due to large temperature differences, repeated thermal cycles causing connection loosening, freeze-thaw cycles also have an impact.
Material aging: Rubber pads losing elasticity, metal fatigue, anti-loosening washer failure.
Treatment methods generally involve retightening bolts to specified torque, replacing damaged anti-loosening devices, reinstalling helical clamps, replacing the entire clamp in severe cases, and considering installation of vibration dampers and other anti-vibration devices.
Rubber Aging
Main manifestations include rubber hardening and cracking, loss of elasticity becoming brittle, surface powdering, obvious color changes such as whitening or yellowing, and detachment or breakage. Causes of rubber aging include UV radiation, temperature effects, and material quality issues. Treatment for rubber aging generally involves replacement every 5-8 years, 3-5 years in coastal and polluted areas, selecting UV-resistant and aging-resistant materials, using protective sleeves, and applying specialized protective agents.
Metal Corrosion
Main manifestations include surface rust and oxide layers, pitting and cavities, coating peeling, strength reduction, and poor electrical contact in OPGW cables. Most causes are environmental corrosion, followed by electrochemical reactions. Treatment methods require grading based on corrosion severity:
Light corrosion: Remove corrosion layer, apply rust-preventive paint or anti-corrosion coating, and strengthen daily protection.
Moderate corrosion: Remove rust and recoat, replace severely corroded components, install anti-corrosion protective sleeves.
Severe corrosion: Complete clamp replacement required, assess adjacent clamp status, switch to higher anti-corrosion grade products.
Preventive measures recommend using stainless steel or hot-dip galvanized products, adding insulating gaskets between different metals, regularly applying anti-corrosion materials, and maintaining good drainage to avoid water accumulation.
Cable Wear
Main manifestations include sheath indentations and depressions, cable surface wear and abrasion, local deformation and twisting, increased fiber attenuation, and in severe cases, cable breakage. Mechanical friction accounts for most causes, including cable micro-movement friction within the clamp, reciprocating wear caused by wind-induced vibration, sharp clamp edges cutting, and rubber pads losing protective function due to aging. Stress, improper installation, and environmental factors are secondary causes.
Treatment for cable wear also requires graded handling:
Minor wear: Adjust clamp position away from wear point, replace aged rubber protective pads, add cushioning protection materials, monitor fiber attenuation changes.
Moderate wear: If sheath is damaged but inner layers are intact, wrap with protective tape, install anti-abrasion sleeves, adjust clamp grip force, consider installing anti-vibration devices.
Severe wear: Must replace damaged cable section, re-evaluate clamp selection, improve installation methods, increase suspension points to reduce span.
Preventive measures include selecting clamps with soft rubber lining, ensuring cable centering during installation, allowing sufficient thermal expansion and contraction margin, regularly inspecting and replacing rubber pads (5-8 years), installing anti-vibration devices in large spans and severe vibration areas, and strictly controlling bend radius requirements to be greater than 20 times the cable diameter.
FAQ
Q: What's the difference between suspension clamps and down-lead clamps?
A: Suspension clamps are used on tangent towers, only supporting cable weight, allowing longitudinal cable sliding, and bearing vertical loads. Down-lead clamps are used on angle and terminal towers, completely anchoring cables without allowing movement, bearing full cable tension, with grip force and tensile strength far exceeding suspension clamps.
Q: Can ADSS suspension clamps be used for OPGW?
A: No, they cannot be mixed. ADSS is all-dielectric non-metallic structure, while OPGW contains steel core and aluminum-clad layers. The two have completely different weight, structure, and electrical properties. OPGW is heavier and requires good grounding, while ADSS clamps have insulated design. Using incorrect clamps can lead to insufficient grip force, grounding failure, and other safety hazards.
Q: How to determine the required load rating?
A: Calculation formula: Load = Cable weight × Span × (1 + Ice coefficient) × Safety factor (2.5-3)
Quick selection:
Short span (<100m): Light-duty type.
Medium span (100-300m): Medium-duty type.
Long span (>300m): Heavy-duty type.
Heavy ice zones, high wind pressure areas: Require special calculation or higher rating selection.
Consulting cable manufacturers or design institutes for accurate calculation is recommended.
Q: What is the expected lifespan of suspension clamps?
A: Design life: 20-30 years.
Actual lifespan depends on:
Material: Stainless steel/high-quality aluminum alloy 25-30 years, ordinary aluminum 15-20 years.
Environment: Coastal salt spray areas 15-20 years, industrial pollution areas 20-25 years, normal environment 25-30 years.
Installation and maintenance: Proper installation + regular inspection (every 3-5 years) can achieve design life.
